ROBO-8115VG2AR is based on Intel?W480E chipset and workstation processors. Built with flexible PCI express expansions, ROBO-8115VG2AR is suitable for Medical, Industrial automation, and Digital Signage application.
| MODEL | ROBO-8115VG2AR |
| Form Factor | PICMG1.3 |
| CPU | Intel? Xeon? W/ Core? i3/i5/i7/i9/Pentium?/ Celeron? |
| Chipset | Intel? W480E |
| BIOS | AMI UEFI |
| Memory | 4 x DDR4 ECC DIMM up to 128GB |
| Expansion | 4x PCI slots 1x PCIe x16 slot or 2x PCIe x8 slots or 1x PCIe x8 slot 2x PCIe x4 slots 1x PCIe x4 slot |
| Display | DVI-I / HDMI |
| Audio | Realtek ALC888S HDA codec |
| LAN | 2x GbE |
| Serial Port | 2x RS-232 ports 2x RS-232/422/485 |
| USB | 6x USB3.2 Gen2 8x USB2.0 |
| Storage Devices | 5x SATA III 1x M.2 Type M 2280 |
| GPIO | 8 bit |
| Others | PS2/KB & MS |
| Dimension | 338.5 x 126.39mm |
| AB1-3K28 | (R).ROBO-8115VG2AR. PICMG 1.3(PCI-E+PCI).LGA1200. W480E PCH. Intel Xeon/Core i3 processors.SHB.w/VGA/Dual GbE/Audio/four COM ports |
| Standard | B6902932 SATA III cable |
| B8981980 PICMG SBC Handling and Installation Notice | |
| B6903351 (GP).Cable.Video DVI-I to DVID+VGA Y cable L=150mm.0130-069-00-0263. E-CALL | |
| B6902352 *(GP).Cable.DB9x2 to HSG(5×2)x2 L=300mm W/Bracket for Ruby-9717/Ruby-9718. CY-8A08006R.CHUAN YANG | |
| TBD Installation CD | |
| Optional | B6903090 USB 3.0 cable with bracket B6902980 PS/2 Keyboard / Mouse Cable with bracket B6902230 USB port cable with bracket |
